Bluetooth Wireless 2.4G Phone Code Paper 2D QR Code NFC Barcode Scanner
Physical Parameters Scanner Dimension 95L*77W*67H mm Scanner Weight About 223g ( Battery included) Scanner Material ABS Holder Dimension 101L*70W*60H mm (Optional) Holder Weight About 91g Holder Material Iron Sensor Image, CMOS Sensor Speed 1/200s Field of View: 70°, 55°, 45° Performance Characteristics 1-D: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, ISBT 128, Code 39, Code93, Code 11, Interleaved 2 of 5, Industrial 2 of 5, Matrix 25, Standard 25, Codabar, MSI/MSI PLESSEY, GS1 DataBar, etc. 2-D: PDF417, QR code, Data Matrix, Aztec code, Hanxi code, etc. Minimum Resolution: 1d ≥4 mil; 2d ≥7.5 mil Scanning depth of field Test Condition Depth of field Code128, 10mil, 18bytes Paper code 0-90mm Code128, 18bytes Screen code 0-120mm QR, 10mil, 160bytes Paper code 0-55mm DM, 15mil, 100bytes Paper code 0-90mm QR, 18bytes Screen code 0-255mm Contrast Ratio ≥25% Indicator Buzzer, LED light Date Transfer USB TYPE-C, Bluetooth, 2.4G Trigger Mode Infrared once or Infrared continuous(by option) Settings By scanning the setting codes Radio Frequency 2400MHz Communication Distance 70m(Open area) Transmission Speed 1Mbps Electric Current 250 mah (working);50 mah (standby);Dc 5 v ±0.25 v (charge) Power Supply 5A-1A Adapter Supply(2000mA built-in battery (Optional)) NFC Card Type 13.56Mhz contactless IC card reader, supports Type A/B card reading Reading Distance Up to 7cm LED Fill-in Light White Environment Operating Temperature 0°C to 45°C Storage Temperature -40°C to 60°C Electrostatic Protection ±15kV (Air discharge); ±8kV (Direct discharge) Certification CE Contact Person :Ms Amy E-mail:sales02@masung.com.cn whatsapp:86-153-9999-1274
