Wltoys XK A220 P40 Mini Warbird Part 4 (Testing on Lua Script, Pascal's Protocal) Radiomaster Tx16s
Wltoys XK A220-P40 FIGHTER 3D/6G EPP Foam Airplane 384mm Right after my maiden I noticed that some pilot in Rcgroups able to bind this little warbird with Radiomaster Tx16s. So I try to dig deeper and Thanks to kiwi_craig, I able to obtain the protocal! The Protocal as follow, for Radiomaster Tx16s, Protocal V911S / E119. For those who want to experience the LUA script, you can get the information in the link below, https://www.rcgroups.com/forums/showpost.php?p=46522917&postcount=436 For Pascal's Protocal, currently it is in testing mode, It will be release as soon as we have an update from OpenTx. To bind the plane, the protocal are the same, Protocal V911S / E119. but if you would like to try it same as me, the download link as follow, https://downloads.multi-module.org/latest-test/ To set it to switch between 3D and 6G mode, below are the channel to do so, CH1 - Ale CH2 - Ele CH3 - Thr CH4 - Rud CH5 - --- - skip CH6 - Rate = -100% High, +100% Low CH7 - 6G_3D = -100% 6G, +100% 3D you can perform all tricks that you want to throw on it. Roll, Loop, or inverted... you name it! this little P40 can do it with a dime! Enjoy the flight Wingspan 4Channel 6 Axis-Gyro RC Plane RTF Features: 1. It is scaled down based on the actual P40 fighter jet. The four-channel design is simple and easy to learn. The aileron channel controls the aircraft to turn left and right, the elevator controls the aircraft to climb and descend, and the throttle channel controls the speed of the aircraft. The direction controls the plane to turn left and right in a circle. The blades, motors, and wings are detachable for easy replacement. The flight control system adds two receiver conversion sockets. 5V is suitable for FUTABA (S-BUS) J and other receivers with (S-BUS) ports, and 3V is suitable for DSM receiver. 2. EPP+ engineering plastics, the flying weight is about 66g. 3. Built-in six-axis gyroscope flight self-stabilization system, with 1020 motor super-powered deceleration group, the route lock is more stable. The remote control 6G/3D mode can be switched at will, and the 6G mode is suitable for beginners to fly. The 3D mode can realize somersaults and side-to-side rolls. It is recommended to fly the aircraft to a certain height during operation to avoid improper operation and reduce the possibility of crashes. 4. USB special charger, more effectively protect the battery from overcharging. 5. The aircraft is fully assembled with the yellow color of the whole fuselage, and it can fly right away. 6. The operation is simple, and even beginners can easily master it. Specification: Brand: XK/Wltoys Model: A220-P40 Material: EPP Wingspan: 384mm Length: 328mm Flying weight: 66g Flight time: about 10 minutes Charging time: 50 minutes Remote control mode: 2.4G remote control Remote control distance: about 150 meters Motor:1020 Coreless motor Battery: 3.7V 400mAh 20C
