My new ZVS driver, 260w driver with huge arcs!!!
This is a demonstration of my new circuit, it's the same as last time but i upgraded the transistors and the power supply, i'm getting the same spark length as last time, with the difference that this is a single flyback and last time i had two in series Materials: X1 Heatsink x2 IRFP250N x2 470 Ohm Resistors 2w (i used 1w and they get a litle hot x2 10k Resistors x2 12v 1w Zener Diodes x2 MUR460 Fast Diodes X1 iron powder 130uH Inductor X1 flyback Transformer x2 0.33 uF 630v Capacitors this is a simple circuit but You can get shocked, also keep the flyback away from the power supply, i damaged the 12v 20A Power Supply from the last vídeo by the corona discharge of the flyback
