Webinar - Analog schematic capture & simulation with Stefan Schippers
Make sure you watch HD & full screen. Stefan’s youtube channel: https://www.youtube.com/channel/UCEgBTPGi5GcVJdReXL-UBNg Installation of Xschem: https://www.youtube.com/watch?v=bYbkz8FXnsQ Harald Pretl’s docker: https://github.com/iic-jku/iic-osic-tools Proppy’s conda install: https://github.com/proppy/conda-eda Join the open source silicon slack: https://invite.skywater.tools/ 00:00 Introduction & News 04:35 Welcome Stefan 09:28 Part 1 - Goals and Schematic capture 21:59 Part 1 Q&A 28:25 Part 2 - Hierarchy 32:53 Part 2 Q&A 37:34 Part 3 - Stimulus 44:07 Part 4 - Simulation setup 50:44 Part 3&4 Q&A 53:46 Part 5 - Running the simulation 59:06 Part 6 - Checking the results 1:03:19 Part 5&6 Q&A
