Camera supraveghere IP Hikvision DS-2CD2183G0-I 8MP - www.1cctv.ro
http://www.1cctv.ro Prezentare Camera supraveghere IP Hikvision DS-2CD2183G0-I 8MP Camera Image Sensor: 1/2.5" Progressive Scan CMOS Signal System: PAL/NTSC Min. Illumination: Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR Shutter time: 1/3 s to 1/100,000 s Slow shutter: Support Lens: 2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124° Lens Mount: M12 Adjustment Range: Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° Day& Night: IR cut filter with auto switch Wide Dynamic Range: 120 dB Digital noise reduction: 3D DNR Focus: Fixed Compression Standard Video Compression: H.265+/H.265/H.264+/H.264/MJPEG Video bit rate: 256Kbps~16Mbps Audio bit rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) Triple Streams: Yes Image Max. Image Resolution: 3840 × 2160 Frame Rate: 50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) Sub Stream: 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Third Stream: 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) Image Enhancement: BLC/3D DNR/BLC Image Settings: Brightness, saturation, contrast, sharpness are adjustable via web browser or client software Target Cropping: No ROI: 1 fixed region for main stream and sub-stream Network Network Storage: microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour General Function: One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering System Compatibility: ONVIF (Profile S, Profile G),ISAPI Interface Communication Interface: 1 RJ45 10M / 100M Ethernet interface Alarm: 1 input, 1 output On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB Reset Button: Yes Smart Feature-set Behavior Analysis: Line crossing detection, intrusion detection Line Crossing Detection: Cross a pre-defined virtual line Intrusion Detection: Enter and loiter in a pre-defined virtual region Recognition: Face Detection General Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F) / Humidity 95% or less (non-condensing) Power Supply: 12 VDC ± 25%, PoE (802.3af Class3) Power Consumption: 12 VDC, 0.6 A, max. 7.5W PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 9W Impact Protection: IK10 Weather Proof: IP67 IR Range: Up to 30m Dimensions: Camera: Φ 111 mm × 82.4 mm (Φ 4.4" × 3.2") Weight: Camera: 500 g (1.1 lb.)
